R1 Dash Delete – with this kit you can remove the stock/OEM dashboard your 2015+ Yamaha R1 or R1M
FTecu 2015-2017 Yamaha R1 Dash Delete now allows you to replace the factory dash with an aftermarket unit and retain full switchable electronic assists.
For off-road track use ONLY!
The Stock bike runs the mode switches to the dash, then directly to the ECU. This means you cannot remove the factory dash and be able to change power modes.
The dash delete allows for use of aftermarket switch pods wired for dedicated mode functions, in order to change your electronic assists on the fly. We include the matching connectors, pins, and weather seals for wiring of your switches.
Switchable inputs that come with our Dash Delete unit are as follows:
• Power Mode +
• Power Mode –
• Lift Control +
• Lift Control-
• Traction Control +
• Traction Control-
• Launch Control
Visit the Document Center for more information on wiring your switches to our Dash Delete unit.
Slide Control is locked to off. QSS is locked to mode 1.
TCS, LIF, and PWR modes save to the last setting once the bike is powered off.
FTecu’s Race Team Subscription, Race Team Professional or Race Team YEC packages are preferred as these give have access to additional data channels in your datalogging and also to setup LCS message on dash.
