6P_BNKT_17 FTecu FlashTune kit for Kawasaki ZX6 / 636 03-04

£415.80£425.00 Excluding tax

Flash-Tune 6P_BNKT_17 FTdataLink ECU Remap & flashing interface cables eliminate the need for plug in third party fueling devices and gives you YEC race kit like performance and features.

Whatsapp us to ask a question !


Your Kawasaki ZX6 / 636 03-04 already has a standalone ECU and now you can get a cable and software to re-program it!

There is no longer any need to send us your ECU to remap, you can buy our DIY kit to fit to your own bike and remap and modify your own ECU!

You can also directly import Power Commander III .djm or Power Commander V 5 .pvm fuel maps!

You can de-restrict and Unleash Your bike’s ECU in 7 Easy Steps!

  •   Select your base map (3 base maps are currently included)
  •   Select your Ycc-T throttle map settings
  •   Select your desired fuel map bias
  •   Select your desired Engine Braking
  •   Import a fuel map file
  •   Choose your options (bypass EURO immobilizer, lower fan temps, speedohealer, rev limiter)
  •   Flash the ECU!

This Interface will remap & flash any ECU from the following bike models!

  • 03-04 Kawasaki ZX6 / 636 03-04 (2003 2004)
  • 21175-0001
  • 21175-0004
  • 211750-0022
  • Other ECU part numbers should be natively readable.

The Flash-Tune Remap Interface allows you to easily adjust the following!

  • (TRE) Removal of all gear based or speed dependent restrictions
  • Optimized timing maps for 91+ octane pump gas
  • Optimized fuel maps
  • +250 RPM Rev limiter
  • Reduced engine braking
  • Bypass immobilizer/IGN switch resister
  • ECU Integrated QS sensor input
  • Disable c2427 trouble codes for aftermarket QS/TC modules
  • Disable pair valve FI code
  • remap STP valve
  • Reduced fan temperatures 205/195°F
  • Disable HOX Sensor
  • Stiffen OEM Damper
  • Disable Set valve
  • Remove Steering Damper FI
  • Reassignment of ABC mapping for fuel types or riding scenarios (commute/race)
  • Remove Ram Air Compensation for Car Applications
  • Disable Speed Sensor c91

Bench ECU Flashing Kit Includes:

  • FTdataLink ECU Interface USB Cable
  • Bench Flashing Harness to flash your ECU outside of the bike
  • Power Supply for Bench flashing
  • FT ECU License to allow unlimited flashes for a single ecu

Flash-Tune FTdataLink ECU Remap & flashing interface cables eliminate the need for the following plug in devices and gives you YEC race kit like performance and features.

– Power Commander or other piggy back fuel controllers
– Power Commander Secondary Fuel Module
– Power Commander Ignition Module
– Bazzaz ZFTi
– Two Brothers JuiceBox
– Leo Vince Fast II fuel and ignition box

ECU flashing is not only more cost effective than its alternatives but it is superior because but it also allows for more precise tuning fuel maps which automatically compensate for changing atmospheric conditions it allows for modification of parameters that are not otherwise tunable such a throttle valve actuation and engine brakingEveryone deserves the same tuning technology that until now was reserved for factory teams and riders with their YEC race kits. With Flash-Tune you can remove the restrictions that the factory must put in place to meet strict street vehicle emissions regulations for homologation, without the need for the factory race loom and factory YEC ECU.

By using Flash-Tune to remap your ECU you are able to remap and tune your bike without interfering with critical correction factors resulting in smoother power gains than ever before possible.

Flash-Tune Remap Products are under constant development. This product is for RACE USE ONLY and may invalidate your warranty.

The included software will automatically update when connected to the internet as new features are added!

With FlashTune from FTecu there is no need for third party fueling devices like Bazzaz or PowerCommander when you ECU flash or your ZX6 or as we call it ZX6 ECU tuning

Additional information

Kit options

USA, International
